Sinotruk 12 Cubic Meter Water Truck

Intercooled Turbo Premium Unleaded V-6

Whether your job site requires dewatering, dust abatement, or general non-potable water supply, the Howo Water Tanker Truck is engineered to get the job done.

Main Features

SINOTRUK

Diesel‌

3.0-Liter V-6

  • Location: China ShanDong
  • Contact Dealer via Phone: (+86)4008801233
  • Existing vehicles: Brand New Cars & Used Cars

Description

It is tailored for professional or marketing use, focusing on the specific technical specifications (5300mm wheelbase, 10-ton capacity) and the “Green Channel” application context.
The Cangzha Truck: Optimized for Green Channel Logistics
The Cangzha truck (or stake-body truck) is a staple in modern logistics, specifically engineered for cargo requiring ventilation or rapid loading/unloading. Its open-top, mesh-sided design makes it an ideal choice for “Green Channel” transport, efficiently handling perishable goods, agricultural products, and bulky freight.
Analyzing a standard model with a 5,300mm wheelbase and a near 10-ton payload capacity reveals a balance of power, durability, and cost-efficiency. When evaluating these vehicles, operators must consider three critical dimensions:1. Powertrain Efficiency: Matching engine output to the demanding requirements of heavy loads and varied terrain.
2. Payload Capability: Maximizing legal load limits while maintaining structural integrity. 3. Structural Design: Ensuring the frame and body configuration support high-volume, fast-turnaround operations. This specific configuration is widely recognized for delivering a reliable return on investment in both urban distribution and intercity freight networks.

Sinotruk 12 Cubic Meter Water Truck – Product Specifications

Basic Information

Product No. APJCF71B06L
Brand HOWO
Product Name ZZ5167GSSK521DF1 Water Sprinkler
Emission Standard China VI (GB17691-2018)

Dimensions

Overall Dimensions (L×W×H) 7410/7900/8400/8900 × 2480 × 3240 mm
Front Overhang / Rear Overhang 1330 / 1880, 1330 / 2070, 1330 / 2370, 1330 / 2370 mm
Approach Angle / Departure Angle 19° / 13°, 19° / 11°, 19° / 10°, 19° / 10°
Wheelbase 4200 / 4500 / 4700 / 5200 mm
Front Track / Rear Track 1940 / 1980 mm (Front), 1800 / 1860 mm (Rear)

Weight & Capacity

Gross Vehicle Weight 16000 kg
Rated Load 8480 / 8415 kg
Curb Weight 7390 kg
Crew Capacity 2 / 3 persons
Load Factor 1.16
Axle Load 5600 / 10400 kg

Performance

Maximum Speed 89 / 95 km/h
ABS Equipped
Fuel Type Diesel

Chassis Configuration

Chassis Model ZZ1167K561DF1 (Class II)
Manufacturer Sinotruk (China National Heavy Duty Truck Group)
Number of Axles 2
Number of Tires 6
Tire Specification 9.00R20, 10R22.5, 275/80R22.5, 10.00R20, 295/80R22.5
Leaf Spring (Front/Rear) 1/1+1, 2/2+2, 3/3+2, 3/4+3, 11/9+8, 11/10+9, 8/9+8, 3/9+8

Additional information

Features

Water Tanker Truck: Your Reliable Partner for Jobsite Water Management

Color

Body Type

Sedan
